LD Systems LAX 1002 analógový mixér

LD Systems LAX 1002 analog mixer

LDLAX1002D - ten inputs, high-quality audio data and a digital effects engine in a compact unit.
With two microphone and four stereo line inputs, the LAX1002 boasts a total of ten inputs within the smallest space - and yet it's still easy to operate. Featuring high-quality premium microphone amps for maximum dynamics and minimum feedback, and three-band tone control plus a switchable lowcut filter in the microphone channels, this compact mixer is the perfect control centre for challenging audio tasks.


• Type: Live
• Channels: 10

Mono Channels:
• Mono Mic and Line Input Channels: 2
• Mono Mic input connectors: XLR, 6.3 mm TRS
• Mono Mic Input Type: electronically balanced
• Mono Mic Input Frequency Range: 10Hz
• Amplification Range mono Mic Input: +10 - +60dB
• Mono Mic Input Input THD-N: 0,005%
• Mono Mic Input Impedance: 2.600Ohm(s)
• Mono Mic Input S/N Ratio: 110dB
• Mono Line Input Type: electronically balanced
• Mono Line Input Frequency Range: 10Hz
• Amplification Range mono Line Input: -10 - +40dB
• Mono Line Input Input THD-N: 0,005%
• Mono Line Input Impedance: 10,000Ohm(s)
• Mono Line Input S/N Ratio: 110dB
• Mono Channel Equalizer Low: +/- 15 dB @ 80 Hz
• Controls Mono Mic and Line Input Channels: Low Cut (75 Hz), 3-band EQ (High, Mid, Low), AUX (DFX) Post, pan, Channel Volume, Gain
• Phantom power: 48 V DC switchable

Stereo Channels:
• Stereo Line Input Channels: 4
• Stereo Line Input Connectors: 6.3 mm TRS
• Stereo Line Input Type: electronically balanced
• Stereo Line Input Frequency Range: 10Hz
• Amplification Range stereo Line Input: +4/-10dB
• Stereo Line Input Input THD-N: 0,005%
• Stereo Line Input Impedance: 20,000Ohm(s)
• Stereo Line Input S/N Ratio: 110dB
• Max. Stereo Line Input Level: +22
• Controls Stereo Line Input Channels: AUX Post, gain switching, Channel Volume, Balance

Main Section:
• AUX / Effects Send Channels: 1
• AUX / Effects Send Connectors: 6.3 mm TS
• Group Out: 1
• Stereo Tape Out Channel: 1
• Stereo Tape Out Connectors: RCA
• Stereo Tape In Channel: 1
• Stereo Tape In Connenctors: RCA
• Balanced Stereo Main Out: 1
• Balanced Stereo Main Out Connectors: 6.3 mm TRS
• Balanced Stereo Main Out Impedance: 240Ohm(s)
• Max. Balanced Stereo Main Out Level: +28
• Stereo Control Room Out Connectors: 6.3 mm TS
• Headphones ouput: 1
• Headphones outputs: 6.3 mm TRS
• Digital Effects Processor: yes
• Number of Presets: 100
• Main section controls: DFX Preset Alpha Dial, Tape to mix, master fader, headphones volume, FX to main, Tape to control room, Phantom Power, FX to control room
• USB media player: no
• Display: Channel Peak, FX Signal, FX Number, Phantom Power, FX Clip, 4-segment Level Meter, Power
• Operating voltage: External Power Supply Prim. 230 V AC 50 Hz Sec. 2 x 16.8 V AC 2 x 500 mA

• Width :217mm
• Height: 55mm
• Depth: 240mm
• Weight: 1,8kg
