Showtec Phantom 50 LED Spot pohyblivá hlava

Showtec Phantom 50 LED moving head

The Phantom 50LED Spot is the bigger brother of the 25LED Spot and has a 50W white LED light source. Besides the stronger output the 50LED spot also has some extra functionality's like rotating gobo´s and a 3-facet prism. The 50LED spot has 8 gobo´s with shake effect and the 9 dichros are the same as the 25LED Spot. This makes them easy to combine. The 50LED Spot can also be used as a master for the 25LED spot in a master/slave setup. It has 2 personalities, an advanced 13-channel and a basic 6-channel setting. The weight is 5,6 Kg and it has only one clamp bracket which makes it easy to handle and position in truss systems. This little moving head will surprise you with its complete functionality and strong light output.
• 18.500 Lux @ 1 M
• 8 Rotating Gobo's & 9 Colors
• easy accessible replaceable gobo's
• Gobo shake, gobo rotate and 3-fact prism
• 16 Built-in programs selectable by DMX

Specifications
Output
• Lux @ 1m: 18.500
• Beam Angle: 17°
• Light Source: 1 x 50W White LED

Electrical
• Input Voltage: 100-240 VAC
• Power consumption: 84W max. at full output
• LED Drive Current: 2A

Control
• On-Board: Display for auto and Sound control
• Control Protocol: DMX512
• Control Personality: Advanced 13ch /Basic 8ch

Optical system
• Dimmer: 0-100%
• Strobe: 0-20Hz
• Focus: Manual focus
• Prism: 3-facet prism

Movement
• Pan: 540°
• Tilt: 270°
• Pan/Tilt resolution: 16 bit
• Special: Pan / Tilt movement blackout
• User-selectable Pan & Tilt ranges, 540°/360°/180°
• Reverse Pan / Tilt movement

Gobos & Colors
• Gobo: 2 glass + 5 metal gobos (replaceable)
• Gobo functions: Gobo-flow effect,Gobo shake
• Rotation: Bi-directional
• Gobo inner diameter: 20mm
• Gobo outer diameter: 24mm
• Colours: 8 dichroic-filters + white
• Colour functions: Split colours, Rainbow-flow effect

Physical
• Colour: Black
• Housing: Metal & Flame-retardant plastic
• Fixture Connection: XLR Data in/out, IEC Power in
• Dimensions (WxDxH): 205 x 210 x 340 mm
• Weight: 5,6 kg

Certification and Safety
• Certification: CE
• Max. ambient Temp.: 40°C
